The 0.65W LED module powered by high output SMD5050 ensures excellent color conformity with no spots in 8-15cm depth signs for utilization in airports, malls, metros, banks, or any other building. The 160 degree beam angle along with special optics allow for even and smooth illumination of the depth sign. The 3 LED chips being encapsulated in 99.99% gold wire along with silver-coated pure copper bracket allows for maximum heat dissipation and product ductility. A maximum of 20pcs modules in a series can be connected and a power wire of less than 2m when maintained between power supply and module ensures consistent brightness all over. As CE, RoHS and UL certified product, the module is safe for use.
The module having a total of 40 pcs of LEDs is eligible for use in both indoor and outdoor conditions as the driver that comes with it is rated as IP65. The IP65 driver protects the module against dust, shock, moisture and even water ejected from the nozzle.
Utilizing the power of SMD LED chips and high quality optics (special lens), the module is capable of emitting light with an angle of 160 degrees which ensures an ultra-wide beam (very wide beam of 120°+40°) of light to cover larger areas with better light distribution by completely eliminating the dark spots.
The LED module has multiple uses such as sign lighting, back lighting, indoor or outdoor commercial sign displays, light boxes and advertisement signs. You can utilise up to 3 modules per square foot of an area.
The module being certified by CE, UL and RoHS meets the minimum regulation for product safety, health and environmental conditions. It’s a risk-free product as you have a 5 years of warranty from the manufacturer’s end.
A CRI of above or equal to 75 on a scale of 100 means the module is above average in color rendering of objects and considered ideal for outdoor depth sign lighting. Further, this module prevents ingress of dust, moisture, shock or even water up to a certain degree.
The LED modules having SMD5050 LED chips are of high quality as they follow ANSI binning standards. These LED chips have been optimized to enable low cost and yet better performance than many cheap quality LED chips available in the market. These LED chips ensure good color conformity with no spot within LED modules.
| Beam Angle: | 160° Beam Angle |
| Brightness: | 20 Lumens |
| Certifications: | UL, RoHS Listed |
| Color Temperature (Kelvin): | RGB |
| Fixture Color: | RGB |
| LED Type: | SMD5050 |
| Lumens: | 20 Lumens |
| Safety Rating: | UL, RoHS Listed |
| UPC: | 719034339726 |
| Warranty: | 5 Years |
| Operating Temperature: | -13 Degree F To 140 Degree F |
| Brand: | LEDMyplace |
| CCT: | RGB |
| Color Rendering Index(CRI): | >75 CRI |
| Dimensions (L x W x H): | 3.42x0.68x0.32 |
| IP Rating: | IP65 Rated |
| Life Hours: | 50,000 Hours |
| MPN (Part No.): | MD012 |
| SKU: | WEN-ZH03QA5-Q |
| Voltage: | 12V DC |
| Wattage: | 0.65Watt |
