Being a part of LEDMyplace' commercial line of products, 240 Watt UFO Led High Bay Lighting is capable of providing lighting to the commercial space with high lumen output. It replaces 840W MH light and the lumen output is comparatively more, making it the best option for lighting up space with ceiling heights 20ft.-30ft. It also gives you the freedom to control the brightness with dimming feature ranging from 1V to 10V. It fits into your ceiling with hook mounting option, with optional ceiling mount and ½" NPT Mount. With a lifespan of 50,000 working hours, LED Shop lights are a perfect replacement for traditional lights that easily get worn out. High Bay LED lights will work for a longer period of time with very little maintenance costs.
Features Of 240 Watt UFO High Bay LED Lights:
It’s an easy installation for the recessed lighting provided through UFO high bay. The hanging ring that comes with our UFO high bay must be inserted into the hole of the lamp and must be tightened through a bolt on the hanging ring itself so that UFO lamp is now firmly fixed. This must be now mounted on the ceiling via a hook. For details, you must check the complete manufacturer’s instructions that come along with the product.
For hook mounting of the UFO high bay, you must have a hook that is heavier than the lamp. Make sure the weight of the hook is 3-4 times heavier than the UFO lamp.
The UFO high bay lighting fixtures come with a big heat sink manufactured out of aluminium for excellent heat dissipation.
In order to maintain highest quality of the product, we use premium LED chips from Epistar. The chips are packaged inside the product with high precision and accuracy to render maximum operational efficiency to the product.
This rating means our UFO high bay is protected against dust-tight and water ingress coming through a nozzle made possible through a driver inside the product.
This product comes with a beam angle that is too wide and not less than 110 degree which is utilized for illumination of wide areas and huge spaces.
The housing of our UFO high bay is designed in rugged die-cast aluminium to impart the fixture the necessary durability for withstanding any external tampering.
Upto 50,000 hours and with very less lumen depreciation till the end of its lifespan, very low maintenance is needed and hence the costs are also low.
The UFO high bay as a dimmable product can be dimmed from 1 volt to 10 volts, 1V being the minimum light level that can be achieved and 10V being the highest level of dimming allowed by the dimmer. At 10 volts, the controlled lighting is at 100% of its potential output. Make sure you have a compatible dimmer for our UFO high bay dimmable light.
The more than standard CRI for UFO high bay helps viewing of objects and surfaces with greater clarity and in their true colors in comparison to what they would look without any artifical lighting.
The motion sensor comes as an accessory and you can choose to have this with our UFO high bay as it helps in alerting you to an intruder especially when you are away.
The UFO high bay being DLC approved comes within the scope of rebate-eligibility criteria and hence you can be eligible for rebate if you decide to have one of our leading products under the commercial segment -- UFO high bay.
This product is compatible with the following dimmers. These dimmers work perfectly with our lights.
**For any other Dimmer please contact our customer support or check with your electrician.
| Beam Angle: | 110° Beam Angle |
| CCT: | 5700 Kelvin |
| Color Rendering Index(CRI): | >80 CRI |
| Diameter: | 15.75 In |
| DLC Listed: | Yes |
| Fixture Color: | Black |
| IP Rating: | IP65 Rated |
| Life Hours: | 50,000 Hours |
| MPN (Part No.): | UF006 |
| Replaces: | 840 Watt Replacement |
| SKU: | WEN-HB02-240WD1-5700K |
| Warranty: | 5 Years |
| Weight: | 16.75 Lbs |
| Brand: | LEDMyplace |
| Certifications: | UL, DLC Listed |
| Color Temperature (Kelvin): | 5700 Kelvin |
| Dimmable: | 1-10V Dimmable |
| DLC Model no.: | WEN-HB07-240WS1BT2A1-abc57 |
| Housing: | Aluminum |
| Lens Type: | Clear Glass |
| Lumens: | 34800 Lumens |
| Power Factor: | >0.9 |
| Shape: | UFO |
| Voltage: | 120V - 277 Volt |
| Wattage: | 240 Watt |
| Operating Temperature: | -4 Degree F To +113 Degree F |
i just built a 40' x 60' x 16' high ceilings how many light should i get
In order to illuminate this high ceiling, you will need approximately 2 lights.
Would the lights be appropriate for a car wash bay? Are they waterproof? Thank you.
These lights are meant for indoor use only, rest these are IP65. I would like to suggest you that you should put these lights at a height where these don't get in contact with water.
I have a 6000sqft space with ceilings that are about 30ft. How many lights would I need to light it?
Hi, I am Kevin from LEDMyplace. Generally, we recommend our customers to put UFOs 10-12 ft apart to get the optimum light. I request you to please send the L, H & W on our email address, so that I can suggest you better.
Contact no. : 815-697-5223
Email : info@ledmyplace.com
Our church forum area 22’ high ceiling 20’ by 20’ how many lights do I need?
You will need 5-6 of these lights approximately.
i have warehouse buildings that are about 25 ft high ceilings. Approximately how many square foot of floor space would one light cover?
It would cover about a 30x30 space.
Will this light work on single phase 120v and with 277v
Yes, it's rated anywhere from 100 to 277V.
How many feet of coverage would I get with these at 15' hanging height.
You'd get about 30ft diameter of light, 300sq ft or so!
do they have tempered glass?
Yes and has die-cast aluminum housing.
How many31,000 Lumes light do you recommend for a 50 x 50’ shop with a 14 foot ceiling
since the ceiling is only 14ft up, we wouldn't recommend the 240W version. We'd recommend our 150W version instead, and you'd need 2-3 lights.
I have a 40x60 with 16’ sidewalls and it is free span so probably around 20’ height in center. I want high bay led round lights, which ones would you recommend and how many would you recommend?
240W - 3 UFO'S
what is measurement size of these lights?
It's diameter is 15.75 inches and height is 7.87 in (including hook)
I need to know the thread type and size
Thread type Hongli 2835 and size is SMD2835(0.5W)
Can this be used outdoor.
Yes, they are IP65 i.e. Moisture and dust resistance
The fixture is rated at 114 degrees F, it can be warmer than that 25' high in building. Could this be an issue?
The fixture is tested for the range of -4° F TO +113° F only. Any variation in temperature could damage the fixture.
